Dual 2.5 Gbps Ports, Engineered for Dense Environments
Delivering high-speed transmissions through dual 2.5 Gbps ports, ER707-M2 is designed for multi-person environments such as retail stores, hotels, and offices. Enjoy a blazing-fast network experience while working from home.
6× WAN Ports & 1 USB WAN for Mobile Broadband
Empowered with up to 6× WAN SFP and RJ45 ports, ER707-M2 supports various internet access.△ Multi-WAN Load Balancing distributes data streams based on the bandwidth proportion of every WAN port to increase the utilization rate of multi-line broadband.
Connect a 4G/3G modem to the USB 2.0 port for a LTE WAN backup.
High-Security VPN
Pass-through traffic and a variety of VPN protocols, such as SSL, GRE§, IPSec, PPTP, and L2TP, are available on ER707-M2, giving consumers versatile options. One-click auto IPSec VPN simplifies VPN configuration and facilitates network management and deployment.* The router also features a built-in hardware engine to boost VPN performance.
Internet Access Management Strategy
Standardize users’ online behavior and easily specify the internet access rights and strategies of employees via IP/MAC/URL Filtering and Access Control List (ACL). Captive Portal authentication facilitates network resource control by capturing, authenticating, and classifying user access. Appropriate network resources can also be allocated for particular users or guests.
Omada SDN—The Smarter Cloud Solution for Business Networking
As the router that seamlessly integrates into the Omada Software Defined Networking (SDN) platform, ER707-M2 allows for remote and centralized management, anywhere, anytime. Standalone management via the Web UI or app is also available to maximize convenience.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
WAN-forbindelse | |
Ethernet WAN | Ja |
SFP WAN | Ja |
Netværk | |
Netværksstandarder | IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3q, IEEE 802.3u, IEEE 802.3x |
Ethernet-grænsefladetype | 2.5 Gigabit Ethernet, Hurtigt ethernet, Gigabit Ethernet |
Ethernet LAN-datahastigheder | 10,100,1000,2500 Mbit/s |
Gennemløb | 1,44 Gbit/sek. |
Statisk rute | Ja |
VLAN understøttelse | Ja |
Politikbaseret routing | Ja |
Administrationsfunktioner | |
Webbaseret administration | Ja |
Universal Plug and Play (UPnP) | Ja |
Knap til nulstilling | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 6 |
Antal WAN/Ethernet LAN-porte | 6 |
Antal WAN-porte | 1 |
Antal installerede SFP moduler | 1 |
Antal USB-porte | 1 |
USB version | 2.0 |
Protokoller | |
DHCP-klient | Ja |
DHCP-server | Ja |
Understøttelse af DMZ | Ja |
Understøttede netværksprotokoller | TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP |
Sikkerhed | |
Sikkerhedsalgoritmer | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1, SNMP, SNMPv2, SNMPv3 |
URL-filtrering | Ja |
ICMP angrebsbeskyttelse | Ja |
Adgangskontrolliste (ACL) | Ja |
Netværk adresse-oversættelse (NAT) | Ja |
System hændelseslog | Ja |
Antal VPN-tunneler | 66 |
Tekniske detaljer | |
Compliance-certifikater | CE, Federal Communications Commission (FCC), RoHS |
Overholdelse af bæredygtighed | Ja |
Funktioner | |
Flashhukommelse | 128 MB |
Intern hukommelse | 1000 MB |
Intern hukommelsestype | DDR4 |
Understøttede Windows-operativsystemer | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
Understøttede Mac-operativsystemer | Ja |
Understøttede Linux-operativsystemer | Ja |
Design | |
Produktfarve | Sort |
Husmateriale | Stål |
Kan monteres på væggen | Ja |
LED-indikatorer | LAN, Link, Strøm, Hastighed, System, USB, WAN |
Strømstyring | |
Strømkilde type | DC |
Udgangsspænding | 12 V |
Udgangsstrøm | 1,5 A |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
Vægt & størrelser | |
Bredde | 226 mm |
Dybde | 131 mm |
Højde | 35 mm |
Emballeringsdata | |
AC-adapter inkluderet | Ja |
Hurtig installationsvejledning | Ja |
Pakkebredde | 242 mm |
Pakkedybde | 323 mm |
Pakkehøjde | 73 mm |
Pakkevægt | 1,1 kg |
