Outstanding usability and control.
Easily manage your office network with 1GbE and 10GbE switches that offer enterprise-class features and intuitive, GUI-based management.
Elegant interface, effortless management
The intuitive graphical user interface (GUI) of Dell Networking X-Series switches makes setup and management simple for network administrators. Based on extensive usability testing, the design of everything from navigation to menu structures and help tips is inspired by the way IT professionals think and work, making the interface a pleasure to use regularly or occasionally.
Save time with smart features
Streamlined tools, step-by-step wizards and a customizable dashboard help you manage faster.
- Rapidly configure and tune network performance with purpose-built tools and wizards.
- Optimize traffic with automation — use point-and-click batch routines for specific applications such as unified communications.
- Gain visibility with a detailed dashboard providing a single, customizable view into common tasks, alerts, port status and network visualization.
- Skip the learning curve and use familiar commands and alerts similar to PCs and servers.
Minimize risk with enhanced visibility and control
Enhanced network traffic visibility and troubleshooting reduces risk of network downtime.
- Monitor and resolve issues with "actionable monitoring," a guided continuous workflow from issue identification to resolution.
- Reduce configuration errors and eliminate extra steps with help from multi-port batch routines and port profiles for common devices.
- Optimize cloud services and onsite network applications with security and traffic-priority features.
Easy integration with your network
Pick the right switch for your network. Choose from a broad selection of models with rich feature sets and a variety of port counts. Power over Ethernet (PoE) and PoE+ models provide additional deployment flexibility, allowing you to connect, auto-configure and power phones, cameras, compact switches and other network devices.
Administrationsfunktioner | |
Switch-type | Administreret |
Switch lag | L2+ |
Servicekvalitet support (QoS) | Ja |
Webbaseret administration | Ja |
System hændelseslog | Ja |
MIB support | Y |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 48 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Antal SFP + modulslots | 4 |
Netværk | |
Netværksstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
10G understøttelse | Ja |
Flowkontrol support | Ja |
Link aggregering | Ja |
Broadcast stormkontrol | Ja |
Auto MDI/MDI-X | Ja |
Spanning tree protokol | Ja |
VLAN understøttelse | Ja |
Antal VLAN'er | 4096 |
Dataoverførsel | |
MAC adresselabel | 16000 entries |
Switch kapacitet | 176 Gbit/sek. |
Gennnemløb | 131 Mpps |
Antal køer | 8 |
Jumbo Frames support | Ja |
Pakke bufferlager | 1 MB |
Sikkerhed | |
DHCP funktioner | DHCP server, DHCP client |
Adgangskontrolliste (ACL) | Ja |
IGMP snooping | Ja |
Statisk port, sikkerhed | Ja |
Multicast funktioner | |
Multicast-understøttelse | Ja |
Protokoller | |
Administrationsprotokoller | SNMPv1, SNMPv2, SNMPv3, SMIv1, SMIv2, IGMPv1, IGMPv2, IGMPv3 |
Understøttede netværksprotokoller | IPv4, IPv6, HTTP, TCP, IP, ICMP, TFTP, BOOTP, UDP, ARP, GARP, GMP, LLDP, RMON, MSTP, UDLD, TLS, PPP, Telnet |
Design | |
Stativ-montering | Ja |
Formfaktor | 1U |
Produktfarve | Sort |
LED-indikatorer | Ja |
Antal blæsere | 2 blæser(e) |
Præstation | |
Støjniveau | 56,7 dB |
Firmware kan opgraderes | Ja |
Strømstyring | |
Udgangseffekt | 100 W |
Strømforbrug (maks.) | 75 W |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ingen |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 45 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 10 - 80% |
Varmeafgivelse | 256 BUT/t |
Vægt & størrelser | |
Bredde | 434 mm |
Dybde | 270 mm |
Højde | 43,5 mm |
Vægt | 3,8 kg |
