2.5G switch | Multi-Gigabit | 5 port | Unmanaged | Cat5e/Cat6/Cat6a cabling | Wall mount kit | K-slot
The unmanaged network switch offers five multi-speed Ethernet ports (10/100/1000/2500 Mbps) in a compact and durable all-metal casing while remaining silent and energy-efficient (IEEE 802.3az). The network switch is the ideal solution to dramatically speed up your network to support 2.5GBASE-T, and being an unmanaged switch, you can set it up in no time.
Enhance your network
This network switch allows you to use existing Cat5e/Cat6/Cat6a cabling to increase the bandwidth to 2.5 Gbps, ideal for large file transfers, streaming, network sharing/storage, or other bandwidth-intensive applications. Auto-negotiation detects the highest supported speeds on your devices for maximum performance and compatibility. You can also use it in combination with Wi-Fi 6 (802.11ax) wireless access points to expand your network range, bandwidth, and accessibility.
Secure and versatile
The 2.5G switch offers a security K-slot for more permanent and secure setups (cable not included). The unintrusive design and small dimensions (6.1x4.7x1.1 inch / 155x120x30 mm) make it easily adaptable to any deployment and has clear diagnostic LEDs that show the status of the devices at a glance. Additional features such as 9K jumbo frames, full-duplex, 16K MAC address table, QoS IEEE 802.1p, and wall mounting kit give you the flexibility to use it in a multitude of scenarios.
The DS52000 is backed for 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.
The StarTech.com Advantage
Administrationsfunktioner | |
Switch-type | Ikke administreret |
Servicekvalitet support (QoS) | Ja |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 5 |
Basis omskiftning RJ-45 Ethernet porttype | 2.5G Ethernet (100/1000/2500) |
Antal 2,5G Ethernet-porte (kobber) | 5 |
Strømstik | DC-in-stik |
Netværk | |
Netværksstandarder | IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
10G understøttelse | Ingen |
Kobber ethernet kabelteknologi | 10BASE-T, 1000BASE-TX, 2500BASE-T |
Understøttede kabeltyper | Cat5e, Cat6, Cat6a |
Fuld duplex | Ja |
Auto MDI/MDI-X | Ja |
Dataoverførsel | |
Switch kapacitet | 2,5 Gbit/sek. |
Opbevar-og-frem | Ja |
Jumbo Frames support | Ja |
Jumbo rammer | 9000 |
Design | |
Stativ-montering | Ingen |
Produktfarve | Sort |
Husmateriale | Stål |
LED-indikatorer | Ja |
Kan monteres på væggen | Ja |
Præstation | |
Maksimal kabellængde | 100 m |
Tekniske detaljer | |
Compliance-certifikater | CE, RoHS |
Strømstyring | |
Strømkilde | Vekselstrøm/jævnstrøm |
Strømforsyning inkluderet | Ja |
Vekselstrømsindgangsspænding | 100 - 240 V |
Indgangsstrøm | 0.5 A |
Udgangsspænding | 12 V |
Udgangsstrøm | 1 A |
Strømstiktype | Type M |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ingen |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 45 °C |
Opbevaringstemperatur (T-T) | -20 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Vægt & størrelser | |
Bredde | 120 mm |
Dybde | 145 mm |
Højde | 30 mm |
Vægt | 600 g |
Emballeringsdata | |
Hurtig start guide | Ja |
Monteringssæt til væggen | Ja |
AC-adapter inkluderet | Ja |
Pakkebredde | 285 mm |
Pakkedybde | 135 mm |
Pakkehøjde | 70 mm |
Pakkevægt | 700 g |
Logistik data | |
Hovedkassens bredde (udvendigt) | 305 mm |
Hovedkassens længde (udvendigt) | 370 mm |
Hovedkassen højde (udvendigt) | 290 mm |
Harmoniseret systemkode (HS) | 85176990 |
Produkter pr. hovedkasse (udvendigt) | 10 stk |
