Instant Connectivity and Reliable Performance
The NETGEAR Gigabit Unmanaged Switch series helps your business cost-effectively expand your network to Gigabit speeds and higher port counts. The GS516PP joins the series and offers 16 PoE+ ports to power high-power PoE devices. With a total PoE power budget of 260W, deploy denser PoE+ devices to a single switch rather than multiple
The GS516PP is energy efficient, built to last, and rigorously tested to provide the reliability your business needs. 802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks.
Powerful and Energy Efficient
Ideal for powering and connecting VoIP phones, wireless access points, IP Cameras and IoT devices. Desktop or rackmount for flexible placement. The GS516PP gives you a highly cost-effective and powerful switch with the best cost/PoE budget ratio.
NETGEAR Unmanaged Switches support the latest Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected. It can further save energy when a short cable is used.
Administrationsfunktioner | |
Switch-type | Ikke administreret |
Servicekvalitet support (QoS) | Ja |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 16 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Netværk | |
Netværksstandarder | IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u |
10G understøttelse | Ingen |
Kobber ethernet kabelteknologi | 10GBASE-T, 100BASE-T, 1000BASE-T |
Fuld duplex | Ja |
Halv dupleks | Ja |
Auto MDI/MDI-X | Ja |
Dataoverførsel | |
MAC adresselabel | 8000 entries |
Switch kapacitet | 32 Gbit/sek. |
Latens (1 Gbps) | 12 µs |
Jumbo Frames support | Ja |
Jumbo rammer | 9216 |
Pakke videresendelsesrate (1 Gbps) | 1448000 pps |
Pakke bufferlager | 0,192 MB |
Sikkerhed | |
Algoritmer for køplanlægning | Weighted Round Robin (WRR) |
Design | |
Stativ-montering | Ja |
Produktfarve | Blå, Grå |
Husmateriale | Metal |
LED-indikatorer | Aktivitet, Ventilatorfejl, Link, PoE, Strøm, Hastighed |
Antal blæsere | 2 blæser(e) |
Certificering | FCC 47 CFR Part15B (Class A) ICES-003 Class A EN 55024/55032/55035 (Class A) AS/NZS CISPR 32 VCCI BSMI CNS13438 KCC UL 62368-1 CB_IEC 60950-1 + IEC 62368-1 Ed-3 LVD EN60950-1+EN62368-1 Ed-2 Rpt AS/NZS 62368.1 Ed-2 BSMI CNS14336-1 |
Præstation | |
Gennemsnitstid mellem fejl (MTBF) | 2415333,9 t |
Strømstyring | |
Strømforsyning inkluderet | Ja |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
Strømforbrug (maks.) | 316,1 W |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet (PoE) -type understøttet | PoE+ |
Power over Ethernet plus (PoE+) porte, antal | 16 |
Power over Ethernet (PoE) effekt pr. port | 30 W |
Total Power over Ethernet (PoE) | 260 W |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 50 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 10 - 95% |
Driftshøjde | 0 - 3000 m |
Vægt & størrelser | |
Bredde | 330 mm |
Dybde | 207 mm |
Højde | 43 mm |
Vægt | 2,3 kg |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
