Cloud Networking, Refreshed
The DBS-2000 series of switches is part of the Nuclias Cloud solution – D-Link’s complete Cloud-Managed Networking solution for Small-to-Medium Businesses (SMBs), designed to make the ownership and administration of your IT infrastructure as simple and hassle-free as possible.
Management Over the Cloud
DBS-2000 is a series of Smart Managed Switches, manageable via the Nuclias Cloud Web Portal through any compatible online PC or Tablet. Connectivity with the Nuclias Cloud platform is guaranteed, with a 99.9% Service-Level-Agreement (SLA), and operation will continue even if the Cloud connection fails.
Easy Troubleshooting
The DBS-2000 Series features Cable Diagnostics and Per Port Traffic Packet Counters to help network admins find & solve network problems. Cable Diagnostics enables quick examination of cable quality, recognition of cable type, and detection of cable errors, with the Per-Port Traffic Packet Counter helping to further isolate problems.
Advanced Security Features
The DBS-2000 series utilizes the Nuclias Cloud Web Portal interface, giving administrators an easy way to manage Layer-2 features, such as VLANs, Spanning Tree Protocol (STP), and 802.3ad Link Aggregation (static). With powerful security features, including IGMP snooping, Static MAC, and end-to-end encryption (WPA/WPA2/WPA3), these Cloud switches are a versatile solution for deployments that require easy configuration, without added complexities.
Full PoE Support
Select models in the DBS-2000 Series support Power over Ethernet (PoE) for copper access ports. Power over Ethernet greatly simplifies the installation of PoE-enabled devices such as VoIP phones and IP cameras in remote locations with no immediate access to a power outlet.
Administrationsfunktioner | |
Switch-type | Administreret |
Switch lag | L2 |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 24 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Kombo SFP porte, antal | 4 |
Netværk | |
Netværksstandarder | IEEE 802.3ad, IEEE 802.3at |
10G understøttelse | Ingen |
Kobber ethernet kabelteknologi | 10BASE-T, 100BASE-TX, 1000BASE-T |
Link aggregering | Ja |
Auto MDI/MDI-X | Ja |
Spanning tree protokol | Ja |
Dataoverførsel | |
MAC adresselabel | 8000 entries |
Switch kapacitet | 56 Gbit/sek. |
Hastighed for videresendelse | 41,7 Mpps |
Pakke bufferlager | 4,1 MB |
Sikkerhed | |
IGMP snooping | Ja |
Sikkerhedsalgoritmer | WPA, WPA2 |
Design | |
Stativ-montering | Ja |
Produktfarve | Grå |
LED-indikatorer | Ja |
Præstation | |
Indbygget processer | Ja |
Processorfrekvens | 500 MHz |
Hukommelsestype | DDR3-SDRAM |
Intern hukommelse | 256 MB |
Flashhukommelse | 32 MB |
Gennemsnitstid mellem fejl (MTBF) | 469262 t |
Tekniske detaljer | |
Forsendelseskassens højde (indvendig) | 39,3 cm |
Forsendelseskasses kassens bredde (indvendig) | 29,5 cm |
Forsendelseskassens længde (indvendig) | 53,9 cm |
Forsendelsesemballage nettovægt | 15,1 kg |
Produkter pr. forsendelseskasse (indvendig) | 3 stk |
Palle bruttovægt (luft) | 403,5 kg |
Antal papkasser pr. palle (luft) | 24 stk |
Antal pr. palle (luft) | 72 stk |
Pallens bruttolængde | 110 cm |
Pallens bruttobredde | 120 cm |
Pallehøjde (luft) | 131,4 cm |
Palle bruttovægt (hav) | 660 kg |
Antal papkasser pr. palle (hav) | 40 stk |
Antal pr. palle (hav) | 120 stk |
Pallehøjde (hav) | 2,1 m |
Forsendelseskassens bruttovægt (indvendig) | 16 kg |
Strømstyring | |
Strømkilde | DC/PoE |
Vekselstrømsindgangsspænding | 100 - 240 V |
Strømforbrug (maks.) | 263,9 W |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet plus (PoE+) porte, antal | 24 |
Power over Ethernet (PoE) effekt pr. port | 30 W |
Total Power over Ethernet (PoE) | 193 W |
Driftsbetingelser | |
Driftstemperatur (T-T) | -5 - 50 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 0 - 95% |
Relativ luftfugtighed ved opbevaring (H-H) | 0 - 95% |
Driftshøjde | 0 - 1500 m |
Varmeafgivelse | 900,36 BUT/t |
Vægt & størrelser | |
Bredde | 440 mm |
Dybde | 250 mm |
Højde | 44 mm |
Vægt | 3,75 kg |
Emballeringsdata | |
Pakkebredde | 365 mm |
Pakkedybde | 521 mm |
Pakkehøjde | 92 mm |
Pakkevægt | 5,04 kg |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
