Pre-configured for out-of-the-box use
NETGEAR IGMP PlusTM enables instant multicast functionality for most AV over IP installations
Dedicated AV web-based GUI interface
Unique interface designed for the AV professional with color-coded, port-based profiles
Profiles for common audio protocols
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license
Video profiles built-in
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed
Unique Automatic Configuration
Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.
Rackmount versatility
1U, 400mm deep rackmount with all power and Ethernet ports on the back
Reversed mounting possibility
Possible reversed mounting with ports in the front including recessed mounting to protect cables
Universal mounting availability
Mounting outside the rack made possible with bottom M5 and front M10 threaded holes
Adjustable fan functionality
Quiet mode with 42dB@25ºC, or fanless mode when PoE load and temperature allow
Easier configuration with new AV GUI
The AV-oriented, web-based GUI permits factory or user-specified profiles to be assigned to individual ports as needed.
Use in noise-sensitive environments
Adjustable fans can be turned off if certain conditions are met. Even the default Quiet mode is quieter than most other switches.
Get up and running fast with little engineering time required
Our NETGEAR IGMP Plus TM feature is set from the factory to ensure out-of-the-box functionality for most AV over IP installations
Multiple mounting options provide ultimate flexibility
Threaded mounting holes sized to industry standards are built into the chassis for mounting behind a display or clamped to a truss.
Administrationsfunktioner | |
Switch-type | Administreret |
Switch lag | L2/L3 |
Porte & Grænseflader | |
Basis omskiftning RJ-45 Ethernet porte, antal | 24 |
Basis omskiftning RJ-45 Ethernet porttype | Gigabit Ethernet (10/100/1000) |
Antal SFP + modulslots | 4 |
Antal USB 2.0-porte | 1 |
Netværk | |
IPv4-ruter | 512 |
IPv6-ruter | 128 |
VLAN understøttelse | Ja |
Antal VLAN'er | 4 |
Dataoverførsel | |
MAC adresselabel | 16000 entries |
Switch kapacitet | 132 Gbit/sek. |
Gennnemløb | 98,21 Mpps |
Latens (1 Gbps) | 2,29 µs |
Latens (10 Gps) | 0,83 µs |
Jumbo Frames support | Ja |
Jumbo rammer | 12000 |
Pakke bufferlager | 16 MB |
Protokoller | |
IPv4 FIB indtastninger | 256 |
IPv6 FIB indtastninger | 16 |
Design | |
Stativ-montering | Ja |
Formfaktor | 1U |
Produktfarve | Sort |
Temperaturføler | Ja |
Præstation | |
Indbygget processer | Ja |
Processormodel | ARM Cortex-A57 |
Støjniveau | 42 dB |
Ventilatorfri | Ja |
Strømstyring | |
Strømforsyning inkluderet | Ja |
Power over Ethernet (PoE) | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet plus (PoE+) porte, antal | 24 |
Power over Ethernet (PoE) effekt pr. port | 45 W |
Vægt & størrelser | |
Bredde | 440 mm |
Dybde | 43,2 mm |
Højde | 400 mm |
Vægt | 5,45 kg |
Emballeringsdata | |
Kabler inkluderet | Vekselstrøm, LAN (RJ-45), USB Type-C |
Rack monteringskit | Ja |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
