The Lenovo ThinkSystem ST250 V3 is a mainstream 1-socket tower server that also be rack mounted as a rack server. It is ideal for small-to-medium businesses, remote offices, branch offices, banking and public sector. The server supports the new Intel Xeon E-2400 Series processors, formerly codenamed "Raptor Lake".
This product guide provides essential presales information to understand the ThinkSystem ST250 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the ST250 V3 and consider its use in IT solutions.
Processor | |
Processorserie | Intel Xeon E |
Processorproducent | Intel |
Processormodel | E-2456 |
Processorfrekvens | 3,3 GHz |
Processor boost frekvens | 5,1 GHz |
Performance-kerner | 6 |
Processorkerner | 6 |
Processor-cache | 18 MB |
Bundkort chipsæt | Intel C266 |
Hukommelse | |
Intern hukommelse | 32 GB |
Intern hukommelsestype | DDR5-SDRAM |
Maksimal intern hukommelse | 128 GB |
Hukommelsesstik | 4x DIMM |
Fejlkorrigerende kode | Ja |
Hukommelsesur hastighed | 4800 MHz |
Hukommelseslayout (slots x størrelse) | 1 x 32 GB |
Lagring | |
Understøtter RAID | Ja |
RAID-niveauer | 0, 1, 5, 10, 50 |
Understøttede RAID-kontroller | 5350-8i |
Hot-swap | Ja |
Interne drevbåse | 8 |
Understøttede lagerdrev brugerflader | SAS, SATA |
Grafik | |
On-board grafikkort | Ja |
Maksimal grafikadapterhukommelse | 16 MB |
Netværk | |
LAN Kontroller | Broadcom BCM5720 |
Ethernet LAN | Ja |
Kabelteknologi | 10/100/1000Base-T(X) |
Ethernet-grænsefladetype | Gigabit Ethernet |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 2 |
Antal USB 2.0-porte | 1 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 5 |
Antal VGA-porte (D-sub) | 1 |
Antal serielle porte | 1 |
Design | |
Kabinettype | Tower |
Produktfarve | Sort |
Præstation | |
Trusted Platform Module (TPM) | Ja |
Trusted Platform Module (TPM) version | 2.0 |
Software | |
Kompatible operativsystemer | Microsoft Windows Server Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
Strømstyring | |
Redundant strømforsyning | Ja |
Strømforsyning | 800 W |
Strømforsyning indgangsspænding | 100 - 240 V |
Strømforsyningens indgangsfrekvens | 50/60 Hz |
Driftsbetingelser | |
Opbevaringstemperatur (T-T) | -40 - 60 °C |
Relativ luftfugtighed ved opbevaring (H-H) | 8 - 90% |
Godkendelser | |
80 PLUS certificering | 80 PLUS Platinum |
Vægt & størrelser | |
Bredde | 176 mm |
Dybde | 578 mm |
Højde | 444 mm |
Tekniske detaljer | |
Understøttede lagringsdrev formfaktor (bagerst) | 2.5" |
