Future defined data center
Lenovo delivers cost-effective, reliable, and scalable solutions by combining industry-leading technology and the world’s best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR650 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, high performance computing and much more.
Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offer an unprecedented combination of high capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.*
* Based on Intel internal testing, August 2018.
Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.
Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
Processor | |
Processorserie | Intel® Xeon® Gold |
Processorproducent | Intel |
Processormodel | 5218R |
Processorfrekvens | 2,1 GHz |
Processorgeneration | Intel Xeon skalerbar 1. generation |
Processor boost frekvens | 4 GHz |
Processor-cache | 27,5 MB |
Bundkort chipsæt | Intel® C624 |
Antal installerede processorer | 1 |
Udfør deaktivering af bit | Ja |
Indlejret tilgængelige muligheder | Ingen |
Hukommelse | |
Intern hukommelse | 32 GB |
Intern hukommelsestype | DDR4-SDRAM |
Hukommelsesur hastighed | 2933 MHz |
Hukommelseslayout (slots x størrelse) | 1 x 32 GB |
Lagring | |
Understøtter RAID | Ja |
Optisk drevtype | Ingen |
RAID-niveauer | 0, 1, 5, 6, 10, 50, 60 |
Understøttede RAID-kontroller | 940-8i 4GB |
Grafik | |
Maksimal grafikadapterhukommelse | 16 MB |
Netværk | |
Ethernet LAN | Ja |
Kabelteknologi | 10/100/1000Base-T(X) |
Porte & Grænseflader | |
Antal USB 2.0-porte | 1 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 3 |
Antal VGA-porte (D-sub) | 1 |
Design | |
Kabinettype | Stativ (2U) |
Produktfarve | Sort, Metallic |
Stativ-montering | Ja |
Understøttelse af redundante blæsere | Ja |
Rack skinner | Ja |
Præstation | |
Målstyring | XClarity Enterprise |
Trusted Platform Module (TPM) | Ja |
Software | |
Kompatible operativsystemer | Microsoft Windows Server 2016 Microsoft Windows Server 2012 R2 Red Hat Enterprise Linux 7.4 Red Hat Enterprise Linux 7.3 Red Hat Enterprise Linux 6.9 Server x64 Edition SUSE Linux Enterprise Server 12 SP3 SUSE Linux Enterprise Server 12 SP2 SUSE Linux Enterprise Server 11 for AMD64/EM64TSP4 VMware vSphere 6.5 (ESXi) Update 1 VMware vSphere 6.5 (ESXi) VMware vSphere 6.0 (ESXi) Update 3 |
Processor særlige funktioner | |
Enhanced Intel SpeedStep Teknologi | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Trusted Execution Teknologi | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® 64 | Ja |
Intel® Virtualization Technology (VT-x) | Ja |
Strømstyring | |
Redundant strømforsyning | Ja |
Strømforsyning | 750 W |
Antal installerede strømforsyninger | 1 |
Strømforsyningens indgangsfrekvens | 50 - 60 Hz |
Driftsbetingelser | |
Driftstemperatur (T-T) | 5 - 45 °C |
Opbevaringstemperatur (T-T) | -40 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 8 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 8 - 90% |
Driftshøjde | 0 - 3050 m |
Vægt & størrelser | |
Bredde | 445 mm |
Dybde | 764 mm |
Højde | 87 mm |
