Lenovo ThinkSystem SR630 is an ideal 2-socket 1U rack server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The SR630 server is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.
This product guide provides essential technical and pre-sales information on the SR630 server, its key features and specifications, components and options, and configuration guidelines.
This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR630 server and consider its use in IT solutions.
Processor | |
Processorserie | Intel® Xeon Silver |
Processorproducent | Intel |
Processormodel | 4214R |
Processorfrekvens | 2,4 GHz |
Processor boost frekvens | 3,5 GHz |
Processor-cache | 16,5 MB |
Bundkort chipsæt | Intel® C624 |
Antal installerede processorer | 1 |
Udfør deaktivering af bit | Ja |
Indlejret tilgængelige muligheder | Ja |
Hukommelse | |
Intern hukommelse | 32 GB |
Intern hukommelsestype | DDR4-SDRAM |
Fejlkorrigerende kode | Ja |
Hukommelsesur hastighed | 2933 MHz |
Hukommelseslayout (slots x størrelse) | 1 x 32 GB |
Lagring | |
Understøtter RAID | Ja |
Optisk drevtype | Ingen |
RAID-niveauer | 0, 1, 5, 6, 10, 50, 60 |
Understøttede RAID-kontroller | 9350-8i |
Grafik | |
On-board grafikkort | Ja |
On-board grafikkort, model | Matrox G200e |
Netværk | |
Wi-Fi | Ingen |
Ethernet LAN | Ja |
Kabelteknologi | 10/100/1000Base-T(X) |
Design | |
Kabinettype | Stativ (1U) |
Produktfarve | Sort, Metallic |
Stativ-montering | Ja |
Understøttelse af redundante blæsere | Ja |
Rack skinner | Ja |
Præstation | |
Målstyring | XClarity Enterprise |
Trusted Platform Module (TPM) | Ja |
Software | |
Kompatible operativsystemer | Microsoft Windows Server 2016 Microsoft Windows Server 2012 R2 Red Hat Enterprise Linux 7.4 Red Hat Enterprise Linux 7.3 Red Hat Enterprise Linux 6.9 Server x64 Edition SUSE Linux Enterprise Server 12 SP3 SUSE Linux Enterprise Server 12 SP2 SUSE Linux Enterprise Server 11 for AMD64/EM64TSP4 VMware vSphere 6.5 (ESXi) Update 1 VMware vSphere 6.5 (ESXi) VMware vSphere 6.0 (ESXi) Update 3 |
Processor særlige funktioner | |
Enhanced Intel SpeedStep Teknologi | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Trusted Execution Teknologi | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® 64 | Ja |
Intel® Virtualization Technology (VT-x) | Ja |
Strømstyring | |
Redundant strømforsyning | Ja |
Strømforsyning | 750 W |
Antal installerede strømforsyninger | 1 |
Strømforsyningens indgangsfrekvens | 50 - 60 Hz |
Driftsbetingelser | |
Driftstemperatur (T-T) | 5 - 45 °C |
Opbevaringstemperatur (T-T) | -40 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 8 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 8 - 90% |
Driftshøjde | 0 - 3050 m |
Vægt & størrelser | |
Bredde | 435 mm |
Dybde | 750 mm |
Højde | 43 mm |
