Top-performing server for data centers needing scalability
Future defined data center
Lenovo delivers cost-effective, reliable, and scalable solutions by combining industry-leading technology and the world’s best software-defined offerings with Lenovo ThinkShield, XClarity, and TruScale Infrastructure Services to manage the life cycle of your data center needs. ThinkSystem SR650 provides support for data analytics, hybrid cloud, hyperconverged infrastructure, video surveillance, high performance computing and much more.
Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offer an unprecedented combination of high capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware.
Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.
Empowering IT management
Lenovo XClarity Controller is the embedded management engine in all ThinkSystem servers that is designed to standardize, simplify, and automate foundation server management tasks. Lenovo XClarity Administrator is a virtualized application that centrally manages ThinkSystem servers, storage, and networking, which can reduce provisioning time up to 95% versus manual operation. Running XClarity Integrator helps you streamline IT management, speed provisioning, and contain costs by seamlessly integrating XClarity into an existing IT environment.
Processor | |
Processorserie | Intel® Xeon® Gold |
Processorproducent | Intel |
Processormodel | 6244 |
Processorfrekvens | 3,6 GHz |
Processorgeneration | Intel Xeon skalerbar 2. generation |
Processor boost frekvens | 4,4 GHz |
Processorkerner | 8 |
Processor-cache | 24,75 MB |
Antal installerede processorer | 1 |
Thermal Design Power (TDP) | 150 W |
Processor sokkel | LGA 3647 (Socket P) |
Processor litografi | 14 nm |
Processortråde | 16 |
Processor driftstilstande | 64-bit |
Processor kodenavn | Cascade Lake |
Tcase | 74 °C |
Maksimal intern hukommelse understøttet af processor | 1,02 TB |
Hukommelsestyper understøttet af processor | DDR4-SDRAM |
Hukommelsesurhastigheder understøttet af processor | 2933 MHz |
Udfør deaktivering af bit | Ja |
Maksimalt antal PCI Express-kanaler | 48 |
Processor-pakke størrelse | 76.0 x 56.5 mm |
Understøttede instruktionssæt | AVX-512 |
Skalerbarhed | 4S |
Indlejret tilgængelige muligheder | Ingen |
Hukommelse | |
Intern hukommelse | 16 GB |
Intern hukommelsestype | DDR4-SDRAM |
Maksimal intern hukommelse | 3 TB |
Hukommelsesstik | 24 |
Hukommelsesur hastighed | 2933 MHz |
Hukommelseslayout (slots x størrelse) | 1 x 16 GB |
Lagring | |
Maksimal lagerkapacitet | 396 TB |
Understøtter RAID | Ja |
Optisk drevtype | Ingen |
Antal understøttede HHD'er | 24 |
Understøttede HDD-størrelser | 2.5" |
RAID-niveauer | 0, 1, 5, 6, 10, 50, 60, JBOD |
Understøttede lagerdrev brugerflader | SAS, Serial ATA III |
Indbygget kortlæser | Ingen |
Grafik | |
Diskret grafikadapter | Ingen |
On-board grafikkort | Ja |
On-board grafikkort, model | Ikke tilgængelig |
Netværk | |
Wi-Fi | Ingen |
Bluetooth | Ingen |
Ethernet LAN | Ja |
Kabelteknologi | 10/100/1000Base-T(X) |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 1 |
Antal USB 2.0-porte | 1 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 3 |
Antal VGA-porte (D-sub) | 1 |
Udvidelsessokler | |
PCI Ekspres x8 slots | 2 |
PCI Express slots version | 3.0 |
Design | |
Kabinettype | Stativ (2U) |
Produktfarve | Sort |
Stativ-montering | Ja |
Understøttelse af redundante blæsere | Ja |
Rack skinner | Ja |
Præstation | |
Målstyring | XClarity Enterprise |
Trusted Platform Module (TPM) | Ja |
Trusted Platform Module (TPM) version | 2.0 |
Software | |
Kompatible operativsystemer | Microsoft Windows Server 2012 R2, 2016, and 2019; Red Hat Enterprise Linux 6 (x64), 7, and 8; SUSELinux Enterprise Server 11 (x64), 12, and 15; VMware vSphere (ESXi) 6.0, 6.5, and 6.7 |
Processor særlige funktioner | |
Enhanced Intel SpeedStep Teknologi | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Hyper Threading Teknologi (Intel® HT Technology) | Ja |
Intel® Turbo Boost Teknologi | 2.0 |
Intel® AES Nye Instruktioner (Intel® AES-NI) | Ja |
Intel® Trusted Execution Teknologi | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® TSX-NI | Ja |
Intel® 64 | Ja |
Intel® Virtualization Technology (VT-x) | Ja |
Processor ARK ID | 192442 |
Strømstyring | |
Redundant strømforsyning | Ja |
Strømforsyning | 1100 W |
Antal understøttede overflødige strømforsyninger | 2 |
Antal installerede strømforsyninger | 1 |
Strømforsyningens indgangsfrekvens | 50 - 60 Hz |
Driftsbetingelser | |
Driftstemperatur (T-T) | 5 - 45 °C |
Opbevaringstemperatur (T-T) | -40 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 8 - 90% |
Relativ luftfugtighed ved opbevaring (H-H) | 8 - 90% |
Driftshøjde | 0 - 3050 m |
Bæredygtighed | |
Bæredygtighedscertifikater | ENERGY STAR |
Vægt & størrelser | |
Bredde | 445 mm |
Dybde | 720 mm |
Højde | 87 mm |
