Best collaboration system for 21:9
Ultra Stretch 105BM5N-B was named winner at InfoComm 2024, earning a Best of InfoComm title for Best Collaboration System for 21:9
21:9 Extended Wide Format
Supporting a 21:9 widescreen aspect ratio, 105BM5N provides an immersive viewing experience. See all your widescreen content or videoconferencing companions.
Proximity Sensor
The 105BM5N features a Proximity Sensor positioned in the middle of its base. This sensor monitors for human activity, and when no movement is observed, it transitions the power to a standby mode.
High Resolution Display
It provides a resolution that's more than 4 times higher than FHD, creating stunning visuals. With a resolution of 5,120 × 2,160 and a high pixel density, every single detail of the display screen is conveyed.
Easily Connect & Charge with USB Type-C
USB Type-C connectivity simplifies connections which enables charging and sending data simultaneously over a single cable.
Wireless ScreenShare
Using the LG CreateBoard Share allows for the seamless & wireless screensharing of presentation materials. It eliminates the clutter of wires leading to a more streamlined meeting space. Show up to 9 shared screens or a file on a screen in real-time when the LG CreateBoard Share app is installed on the device. Also, files from the host can be easily sent to any devices connected to the app.
OPS Slot
105BM5N supports OPS slots, allowing you to conveniently mount OPS Module at the back of the screen without the hassle of connecting to an external desktop, enabling various PC functions and Windows software even on the 105BM5N.
LG ConnectedCare DMS
LG ConnectedCare DMS is a cloud solution for remote monitoring, controlling, and managing the status of devices. This feature enables IT managers to manage important resources on operating devices without physically visiting sites.
Remote Control
Thanks to LG ConnectedCare DMS, IT manager can select specific devices to be controlled remotely and update their settings all at once. General settings, power settings, application management, and multimedia can all be effectively managed and controlled simultaneously, enabling the stable operation of clients' businesses.
Broadcast / Alert Message
Messages and a range of other content can be sent from the main system's hub to individual devices connected to LG ConnectedCare DMS and you can easily display important company notices or schedules right on your device. In case of urgent occasions such as a fire or a natural disaster, alert messages can be distributed manually across the system, which helps people promptly take a safety action.
Display | |
Skærm diagonal | 2,67 m (105") |
Skærmopløsning | 5120 x 2160 pixel |
Skærmens lysstyrke | 400 cd/m² |
HD-type | 5K Ultra HD |
Berøringsskærm | Ingen |
LED-baggrundsbelysning type | Direct-LED |
Naturligt aspektforhold | 21:9 |
Responstid | 6,5 ms |
Kontrastforhold (typisk) | 4000:1 |
Kontrastforhold (dynamisk) | 5000:1 |
Synsvinkel, horisontal | 178° |
Synsvinkel, vertikal | 178° |
Panel levetid | 30000 t |
Farvedybde | 10 Bit |
Oprindelig opdateringshastighed | 60 Hz |
Tågehastighed | 25% |
Farveområde | 72% |
Porte & Grænseflader | |
Antal HDMI-porte | 4 |
Antal DisplayPorts | 2 |
USB-port | Ja |
Ethernet LAN | Ja |
Wi-Fi | Ja |
HDMI-version | 2.0/2.1 |
DisplayPorts indgang | 1 |
DisplayPorts udgang | 1 |
Antal USB-porte | 11 |
Antal USB 2.0 Type-B porte | 6 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 4 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte | 1 |
Ethernet LAN-porte (RJ-45) | 2 |
Wi-Fi-standarder | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Lyd (L, R) indgang | 1 |
Lyd (L, R) udgang | 1 |
RS-232C | Ja |
Lyd | |
Indbyggede højttaler(e) | Ja |
Udgangseffekt (RMS) | 47 W |
Design | |
Produktdesign | Digital fladpaneldisplay |
Produktfarve | Sort |
Understøttet placering | Indendørs |
VESA montering | Ja |
Orientering | Lodret |
Panel montering grænseflade | 1000 x 400 mm |
Facet bredde (bund) | 2,3 cm |
Facet bredde (side) | 3,5 mm |
Facet bredde (øverste) | 3,5 mm |
Præstation | |
Formål | Kommerciel |
Skærmvisning (OSD) | Ja |
Driftstimer (timer/dage) | 16/7 |
HDCP | Ja |
HDCP-version | 2.3 |
OPS (Open Pluggable Specification) | Ja |
Strømstyring | |
Strømforbrug (typisk) | 350 W |
Strømforbrug (standby) | 0,5 W |
Strømforbrug (maks.) | 850 W |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50/60 Hz |
Varmeafgivelse | 1194 BUT/t |
Computersystem | |
Indbygget processer | Ja |
Processorproducent | ARM |
Processorserie | ARM Cortex |
Processor arkitektur | ARM Cortex-A76+Cortex-A55 |
Intern hukommelse | 64 GB |
Intern lagerkapacitet | 8 GB |
Operativsystem installeret | Android |
Version af operativsystem | 13,0 |
Vægt & størrelser | |
Skærmbredde | 2510,6 mm |
Skærm, dybde | 93,6 mm |
Skærm, højde | 1123,1 mm |
Skærm, vægt | 90,1 kg |
Emballeringsdata | |
Pakkebredde | 2668 mm |
Pakkedybde | 1305 mm |
Pakkehøjde | 280 mm |
Pakkevægt | 122,9 kg |
Emballage indhold | |
Fjernbetjening inkluderet | Ja |
Kabler inkluderet | HDMI, Strøm |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Funktioner | |
Varmeafledning (maks.) | 2900 BUT/t |
Tekniske detaljer | |
OPS slot | 1 |
Overfladebehandling | 25 |
Andre funktioner | |
Bluetooth | Ja |
Bluetooth-version | 5.2 |
Antal RJ-45-porte | 2 |
Glasbeskyttelse | Ja |
