With powerful media handling and innovative smart features to ensure a high level of data integrity, the WorkForce DS-770II is geared towards highly-efficient and simple integration into an organisation’s workflow. With a 100-page ADF and the ability to scan at up to 45ppm/90ipm, it offers a wide range of media handling options that enable you to rapidly capture, index, store and share business documents.
Intelligent features improve efficiency, accuracy and data reliability
With an industry-first slow mode1 for scanning crumpled or fragile documents, the ability to scan challenging media has never been easier. The Active Separation Roller System prevents tedious document double feeds ensuring every piece of paper gets scanned and the Double Feed Detection Skip (DFDS) function means you can scan difficult media like envelopes or documents with post-it notes. Auto Scan Mode enables the processing of a vast number of documents as manageable amounts, enabling them to be scanned as one file.
Highly versatile
The optional flatbed scanner conversion kit allows effective document processing from stamps to passports and books. Single-pass double-sided scanning ensures rapid document processing, while it's possible to scan a versatile array of media such as paper as thin as 27gsm, or thick card at 413gsm. The A3 carrier sheet speeds up the process by automatically stitching larger documents back together digitally.
Flexible connectivity
High-speed USB 3.0 with TWAIN, WIA and ISIS drivers for enhanced compatibility with Document Management Systems.
Image enhancement and document management software
Epson Scan 2.0 software makes it easy to edit images with features such as de-skew and auto rotate, while Document Capture Pro is the easy to use solution for capturing and storing electronic documents at the touch of a button.
Scanning | |
Maksimal scanningsstørrelse | 215,9 x 6096 mm |
Optisk scanningsopløsning | 600 x 600 dpi |
Duplex scanning | Ja |
Farvescanning | Ja |
Input farvedybde | 30 Bit |
Output farvedybde | 24 Bit |
Input gråtoneskala dybde | 10 Bit |
Output gråtoneskala dybde | 8 Bit |
Udgang monokrom dybde | 8 Bit |
ADF-scanningshastighed (sort/hvid, A4) | 45 sider pr. minut |
ADF-scanningshastighed (farve, A4) | 45 sider pr. minut |
Duplex ADF-scanningshastighed (sort/hvid, A4) | 90 ipm |
Duplex ADF-scanningshastighed (farve, A4) | 90 ipm |
Design | |
Scanner type | Skanner med papir-tilførsel |
Indbygget skærm | Ja |
Produktfarve | Hvid |
Skærm | LCD |
Præstation | |
Daglig driftscyklus (maks.) | 7000 Sider |
Lyskilde | ReadyScan LED |
Scan filformater | JPEG, PDF, TIFF |
Scan til | E-mail, FTP, Software, Udskriv, Network folder |
Scan drivere | TWAIN, WIA, ISIS |
Ultrasonic sensor | Ja |
Input kapacitet | |
Standard indgangskapacitet | 100 ark |
Automatisk dokumentføder (ADF) indgangskapacitet | 100 ark |
Papirhåndtering | |
Maksimal ISO A-serie papirstørrelse | A4 |
Scanning af understøttede medietyper | Plastkort, Post Card(JPN) |
ISO A-serie, størrelser (A0...A9) | A4, A5, A6 |
ISO B-serie, størrelser (B0...B9) | B5, B6 |
Papirformat | Ja |
Juridisk | Ja |
Automatisk dokumentføder (ADF) medievægt | 27 - 413 g/m² |
Maksimalt scanningsområde (ADF) | 215,9 x 6096 mm |
Mindste scanningsområde (ADF) | 50,8 x 50,8 mm |
Porte & Grænseflader | |
USB-port | Ja |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
Strømstyring | |
Strømforsyningstype | Vekselstrøm |
Strømforbrug (slukket) | 0,1 W |
Funktioner | |
Oprindelsesland | Indonesien |
Emballeringsdata | |
Antal pr. pakke | 1 stk |
Pakkebredde | 250 mm |
Pakkedybde | 365 mm |
Pakkehøjde | 285 mm |
Pakkevægt | 4,58 kg |
Systemkrav | |
Kompatible operativsystemer | Citrix XenApp 5.0, Citrix XenApp 6.0, Citrix XenApp 7.6 und höher, Linux, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8, Windows 8 (32/64 Bit), Windows 8 RT, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2008 (32/64 Bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Vista, Windows Vista, 64-Bit-Version, Windows Server 2003 R2, Windows XP Professional x64 Edition |
Understøttede Windows-operativsystemer | Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 x64, Windows RT, Windows 8.1, Windows 8.1 x64, Windows Vista, Windows Vista x64, Windows XP Professional x64 |
Understøttede Mac-operativsystemer | Ja |
Understøttede Linux-operativsystemer | Ja |
Understøttede operativsystemer til servere | Windows Server 2008, Windows Server 2008 x64, Windows Server 2008 R2, Windows Server 2012 x64, Windows Server 2012 R2, Windows Server 2003 R2 |
Driftsbetingelser | |
Driftstemperatur (T-T) | 5 - 35 °C |
Opbevaringstemperatur (T-T) | -25 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 15 - 80% |
Relativ luftfugtighed ved opbevaring (H-H) | 15 - 85% |
Vægt & størrelser | |
Bredde | 296 mm |
Dybde | 169 mm |
Højde | 176 mm |
Vægt | 3,7 kg |
Emballage indhold | |
Garantibevis | Ja |
Kabler inkluderet | Vekselstrøm |
Drivere inkluderet | Ja |
Medfølgende software | Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Document Capture Pro Server (on free download), Epson Scan 2, Presto! BizCard 5.6 |
Andre funktioner | |
Understøttede billedformater | JPEG, TIFF |
Output opløsninger | 75, 100, 150, 200, 240, 300, 600, 1200 dpi |
Logistik data | |
Produkter pr. palle | 63 stk |
Produkter pr. palle (UK) | 84 stk |
Harmoniseret systemkode (HS) | 84716070 |
