iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.
Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.
Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Porte & Grænseflader | |
Forbindelsesteknologi | Ledningsført |
Værtsgrænseflade | PCI Express |
Grænseflade | Ethernet |
Ethernet LAN-porte (RJ-45) | 2 |
PCI version | 3.0 |
Netværk | |
Maksimal dataoverførselshastighed | 10000 Mbit/s |
Ethernet LAN | Ja |
Ethernet-grænsefladetype | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet |
Ethernet LAN-datahastigheder | 100,1000,2500,5000,10000 Mbit/s |
Maksimal driftstilstand | 100 m |
LAN Kontroller | Intel X710-AT2 |
Design | |
Intern | Ja |
Komponent til | Server/arbejdsplads |
Produktfarve | Sort, Grøn |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
Andre funktioner | |
Kabeltype | RJ45 Category 6, Category 6A, Category 5e up to 100m<br /> |
Intel® Virtual Machine Device Queues (VMDq) | Ja |
PCI-SIG* SR-IOV kompetent | Ja |
On-chip QoS og trafik administration | Ja |
Intel® Fleksibel Port-deling | Ja |
Speed & slot width | 8.0 GT/s, x8 Lane |
Intelligent Offloads | Ja |
iWARP/RDMA | Ingen |
Intel® Data Direct I/O Teknologi | Ja |
Intel® Virtualization Technology for Connectivity (VT-c) | Ja |
Grænsefladetype | PCIe v3.0 (8.0GT/s) |
Produkttype | Network Interface Card |
Processorserie | 700 Network Adapters (up to 40GbE)-700 Network Adapters (up to 40GbE) |
Eksportkontrolklassisfikationsnummer (ECCN) | 5A991 |
Automatiseret sporingssystem til vareklassificering (CCATS) | NA |
Controller type | Intel® Ethernet Controller X710-AT2 |
Beslagshøjde | Low-Profile (LP) / Full-Height (FH) |
Målgruppe | Artificial Intelligence, High Performance Computing |
Opbevaring over ethernet | iSCSI, NFS |
Lanceringsdato | Q3'19 |
Netværkskort kabel medium | Copper |
Netværkskorttype | Server |
Produktbeskrivelse URL | https://www.intel.com/content/www/us/en/products/docs/network-io/ethernet/network-adapters/ethernet-adapter-x710-t2l-t4l-brief.html |
Status | Launched |
Produktserie | 700 Series Network Adapters (up to 40GbE) |
