High-performance mass storage
The 12-bay Synology DS3622xs+ is a powerhouse NAS perfect for the needs of small and medium business environments with intensive and multi-user workloads. Its high capacity, scalability, and processing power make it ideal for VM and container storage, fast file sharing, and as a network video recorder for large surveillance deployments. It comes with powerful storage management, file syncing, surveillance, and backup software, and is suitable for editing high-quality video.
Faster performance
Enjoy a smooth experience even with multiple users running demanding applications. See the numbers that make the DS3622xs+ more efficient.
Rise to the challenge
Prepare your DS3622xs+ for the heaviest workloads or upgrade when needed as your business continues to grow. Use add-in cards to add bandwidth, fast SSD cache, or both.
Out-of-the-box data protection
Protect your data with professional backup software for your Synology NAS, other devices, and applications.
Efficient collaboration and communication
Empower your workforce to collaborate, share files, and communicate from anywhere.
Certified virtual machine storage
Synology DiskStation Manager (DSM) streamlines provisioning for and management of virtual machines with full certification for VMware® vSphere™, Microsoft® Hyper-V®, Citrix® XenServer™, and OpenStack virtualization environments.
Synology Storage Console for VMware® or Windows platforms lets you manage storage directly from your hypervisor. VMware® VAAI integration and Windows ODX help offload storage operations and speed up data transfer, and a Kubernetes CSI driver lets you provision and manage volumes directly from the K8s CLI.
Centralized surveillance for your business
Transform the DS3622xs+ into a powerful network video recorder with Synology Surveillance Station.
Works best with Synology drives
Enjoy top quality performance for any intensive workload with drives specifically designed for Synology NAS.
Get more with DiskStation Manager
Take advantage of a whole host of native productivity, management, and security solutions available on the web-based Synology DSM operating system.
Lagring | |
Datalagringsdriver installeret | Ingen |
Antal understøttede lagerdiske | 12 |
Installeret lagerdisktype | Ingen |
Understøttet datalagringsdrev typer | HDD & SSD |
Understøtter RAID | Ja |
Understøttede lagerdrev brugerflader | SATA, Serial ATA II, Serial ATA III |
Understøttede lagerdisk størrelser | 2.5,3.5" |
Maksimalt understøttet lagerkapacitet | 200 TB |
RAID-niveauer | 0, 1, 5, 6, 10, JBOD |
Hot-swap drevbåse | Ja |
Understøttede filsystemer | BTRFS, Fedt, HFS+, NTFS, ext3, ext4 |
Processor | |
Processorserie | Intel® Xeon® D |
Processorproducent | Intel |
Processormodel | D-1531 |
Processorfrekvens | 2,2 GHz |
Processor boost frekvens | 2,7 GHz |
Processorkerner | 6 |
CPU-konfiguration (maks.) | 1 |
Antal understøttede processorer | 1 |
Konfliktfri processor | Ja |
Hukommelse | |
Intern hukommelse | 16 GB |
Intern hukommelsestype | DDR4 |
Maksimal understøttede RAM | 48 GB |
Hukommelsesstik | 4 |
Hukommelse form faktor | SO-DIMM |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-datahastigheder | 1000,10000 Mbit/s |
Wake-on-LAN klar | Ja |
Understøttede netværksprotokoller | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Link aggregering | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 4 |
USB-port | Ja |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
PCI Ekspres x8 (Gen 3.x) slots | 1 |
Design | |
Kabinettype | Tower |
Kølingstype | Aktiv |
Produktfarve | Sort |
Antal blæsere | 2 blæser(e) |
Ventilator diameter | 12 cm |
Blæser 2, diameter | 12 cm |
Præstation | |
Type | NAS |
Enhedsklasse | Hjem & hjemmekontor |
Backup funktion | Ja |
Flersproget support | Ja |
Støjniveau | 25 dB |
Webbaseret administration | Ja |
Adgangskontrolliste (ACL) | Ja |
Understøttet browser | Safari, Google Chrome, Firefox, Microsoft Edge |
Software | |
Operativsystem installeret | DiskStation Manager |
Understøttede operativsystemer til servere | Windows Server 2016, Windows Server 2019 |
Strømstyring | |
Placering af strømforsyning | Indbygget |
Strømforsyningens kapacitet (PCU) | 550 W |
Antal strømforsyninger | 1 |
Strømforbrug (typisk) | 94,42 W |
Strømforbrug (HDD standby) | 54,33 W |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
Vægt & størrelser | |
Bredde | 300 mm |
Dybde | 340 mm |
Højde | 270 mm |
Vægt | 9,8 kg |
Emballage indhold | |
Kabler inkluderet | Vekselstrøm, LAN (RJ-45) |
Processor særlige funktioner | |
Indlejret tilgængelige muligheder | Ingen |
Enhanced Intel SpeedStep Teknologi | Ja |
Udfør deaktivering af bit | Ja |
Idle status | Ja |
Intel® 64 | Ja |
Intel® Enhanced Halt State | Ja |
Intel® Secure Key Technology version | 1,00 |
Intel® Trusted Execution Teknologi | Ja |
Intel® TSX-NI | Ja |
Intel® TSX-NI-version | 1,00 |
Intel® Virtualization Technology (VT-x) | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Relativ luftfugtighed ved drift (H-H) | 5 - 95% |
Opbevaringstemperatur (T-T) | -20 - 60 °C |
Logistik data | |
Harmoniseret systemkode (HS) | 84714100 |
Andre funktioner | |
Certificering | FCC CE BSMI VCCI RCM UKCA EAC KC UL |
