The QVP-21C QVR Pro appliance is a tower-based network surveillance server with an Intel® Celeron® quad-core processor that supports eight free IP camera channels and up to sixteen IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-21C fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.
Supports ONVIF cameras
Compatible with thousands of cameras from over 190 brands and ONVIF standards.
Long-term model
The QVP-21C will be available and supported by QNAP for an extended period, up to 2029.
Dual HDMI™ outputs
Play and switch between multi-channel real-time 4K videos on two monitors with extended display.
High-performance NVR
Boost your surveillance data transmission efficiency with dual-port 2.5GbE, a USB 3.2 Gen2 10Gbps port, and 8GB RAM.
RAID protection
Unlike traditional DVR and NVR, the QVP-21C protects your data from drive failure with RAID.
Lightweight AI surveillance applications
QVP-21C incorporates QNAP smart surveillance applications and supports Intel® OpenVINO™ AI engine and Edge TPU expansion via M.2 SSD slots to boost facial recognition performance in QVR Face.
QVP-21C vs. other NAS-based surveillance systems. What’s the difference?
In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-21C QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-21C also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-21C to start the installation process.
Lagring | |
Datalagringsdriver installeret | Ingen |
Antal understøttede lagerdiske | 2 |
Installeret lagerdisktype | Ingen |
Understøttet datalagringsdrev typer | HDD & SSD |
Understøtter RAID | Ja |
Understøttede lagerdrev brugerflader | M.2, Serial ATA III |
Understøttede lagerdisk størrelser | 2.5,3.5,M.2 |
RAID-niveauer | 0, 1, 5+HS, 5, 6, 10+HS, 10, JBOD |
Online RAID-migrering | Ja |
Hot-swap drevbåse | Ja |
Understøttede filsystemer | ext4 |
Processor | |
Processorserie | Intel® Celeron® |
Processorproducent | Intel |
Processormodel | J6412 |
Processor boost frekvens | 2,6 GHz |
Processorkerner | 4 |
On-board grafikkort, model | Intel® UHD Graphics |
Hukommelse | |
Intern hukommelse | 8 GB |
Intern hukommelsestype | DDR4 |
Hukommelsesur hastighed | 3200 MHz |
Maksimal understøttede RAM | 16 GB |
Hukommelsesstik | 2 |
Hukommelse form faktor | SO-DIMM |
Flashhukommelse | 4000 MB |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-datahastigheder | 2500 Mbit/s |
DHCP-server | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 2 |
USB-port | Ja |
Antal USB 2.0-porte | 2 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 2 |
Antal HDMI-porte | 2 |
HDMI-version | 1.4b |
Design | |
Kabinettype | Tower |
Kølingstype | Aktiv |
Produktfarve | Sort |
Antal blæsere | 1 blæser(e) |
Ventilator diameter | 7 cm |
LED-indikatorer | Ja |
Præstation | |
Type | Lagringsserver |
Enhedsklasse | Hjem & hjemmekontor |
Backup funktion | Ja |
Lydalarm | Ja |
Støjniveau | 15,4 dB |
Video indgangskanaler | 8 kanaler |
Snapshot | Ja |
Knap til nulstilling | Ja |
Tænd-/slukkontakt | Ja |
Understøtter S.M.A.R.T. | Ja |
Software | |
Operativsystem installeret | QVR Pro |
Strømstyring | |
Strømforbrug (typisk) | 60 W |
Vekselstrømsindgangsspænding | 100 - 240 V |
Vægt & størrelser | |
Bredde | 102 mm |
Dybde | 220,5 mm |
Højde | 169,2 mm |
Vægt | 1,57 kg |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Relativ luftfugtighed ved drift (H-H) | 5 - 95% |
