ReadyNAS 3312 and 4312X are powered by a 5th generation Intel Xeon Enterprise Server Processor. The RR4312X has two built-in 10Gigabit Ethernet interfaces to meet the throughput speed of next generation network in businesses of all sizes.
Application data, virtual images, client files, email… the types of data central to running a successful business can seem endless. With ReadyNAS you finally have an advanced and easy-to-use solution for centralizing, securing and controlling access to your digital assets. Way more than just simple unified (NAS and SAN) storage for your company, ReadyNAS allows you to do more than you ever thought you could afford by pairing the latest in performance with innovative efficiency technologies such as unlimited snapshots, thin provisioning and cloud-managed replication.
Every networked attached storage (NAS) device from NETGEAR runs on the revolutionary ReadyNAS operating system. This custom-built OS protects stored data with XRAID2™ automatic expansion and offers continuous data protection with unlimited snapshots.
Real-time anti-virus and native encryption comes standard. The RR4312 Series offers two builtin 10GbE ports, requiring no additional installation and offering compatibility assurance.
Designed specifically for the unique needs of business users, ReadyNAS devices utilize proprietary ReadyCLOUD™ technology for cloud-based discovery, provisioning and ongoing management. In addition, these devices are virtualization-ready with iSCSI support, thin provisioning capability and certification with VMware and Microsof.
To maximize storage capacity, ReadyNAS 4312X features two SAS interfaces for expansion chassis support. Expansion chassis from NETGEAR, EDA4000 and EDA2000, offer 24 and 12 bay expansion respectively.
Lagring | |
Datalagringsdriver installeret | Ingen |
Antal understøttede lagerdiske | 12 |
Installeret lagerdisktype | Ingen |
Understøttet datalagringsdrev typer | SSD |
Grænseflade til lagerdisk | Serial ATA III |
Understøtter RAID | Ja |
Maksimalt understøttet lagerkapacitet | 120 TB |
RAID-niveauer | 0, 1, 5, 6, 10, JBOD |
Hot-swap drevbåse | Ja |
Understøttede filsystemer | FAT32, HFS+, NTFS, ext3, ext4 |
Processor | |
Processorserie | Intel® Xeon® E3 v5, Intel Xeon E3-1200 v5 |
Processorproducent | Intel |
Processormodel | E3-1245V5 |
Processorfrekvens | 3,5 GHz |
Processor boost frekvens | 3,9 GHz |
Processorkerner | 4 |
Processortråde | 8 |
Processor-cache | 8 MB |
Bus type | DMI3 |
CPU-konfiguration (maks.) | 1 |
Fejlkorrigerende kode understøttet af processor | Ja |
PCI Express-konfigurationer | 1x16, 1x8+2x4, 2x8 |
PCI Express slots version | 3.0 |
Processor cache type | Smart cache |
Processor kodenavn | Skylake |
Processor litografi | 14 nm |
Processor driftstilstande | 64-bit |
Processor-pakke størrelse | 37.5 x 37.5 mm |
Processor sokkel | LGA 1151 (stik H4) |
Skalerbarhed | 1S |
Stepping | R0 |
Systembus-hastighed | 8 GT/s |
Thermal Design Power (TDP) | 80 W |
On-board grafikkort, model | Intel® HD Graphics P530 |
Maksimal intern hukommelse understøttet af processor | 64 GB |
Hukommelsesbåndbredde understøttet af processor (maks.) | 34,1 GB/sek. |
Konfliktfri processor | Ja |
Hukommelse | |
Intern hukommelse | 16 GB |
Intern hukommelsestype | DDR4 |
Maksimal understøttede RAM | 128 GB |
Flashhukommelse | 256 MB |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-datahastigheder | 10,100,1000,10000 Mbit/s |
Wi-Fi | Ingen |
DHCP-klient | Ja |
Jumbo Frames support | Ja |
iSCSI-understøttelse | Ja |
Understøttede netværksprotokoller | TCP/IP, HTTP, HTTPS, FTP, SSH |
Balance system | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 4 |
USB-port | Ja |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
Fiberkanal porte | 2 |
Fiber optisk strømstik | SFP+ |
Antal eSATA-porte | 2 |
Grafik | |
Indbygget grafikadapter basefrekvens | 400 MHz |
Indbygget grafikadapter dynamisk frekvens (maks.) | 1150 MHz |
Indbygget grafikadapter DirectX-version | 12.0 |
Indbygget grafikadapter OpenGL-version | 4.4 |
Indbygget grafikadapter-ID | 0x191D |
Maksimalt indbygget grafikadapterhukommelse | 1 GB |
Antal understøttede skærme (indbygget grafik) | 3 |
Design | |
Kabinettype | Stativ (2U) |
Kølingstype | Aktiv |
Produktfarve | Sort |
Antal blæsere | 3 blæser(e) |
Ventilator diameter | 8 cm |
LED-indikatorer | Ja |
Præstation | |
Type | NAS |
Backup funktion | Ja |
Backup detaljer | Cloud |
Antal brugere | 8192 bruger(e) |
Støjniveau | 30 dB |
Webbaseret administration | Ja |
Filmappe rettigheder med korrekt administration | Ja |
Adgangskontrolliste (ACL) | Ja |
Tænd-/slukkontakt | Ja |
Indbygget BitTorrent klient | Ja |
Indbygget UPnP™ AV -medieserver | Ja |
Indbygget iTunes server | Ja |
Understøttet browser | Microsoft Internet Explorer 9+, Mozilla Firefox 14+, Google Chrome 20+, Apple Safari 5+ |
Netværkstidsprotokol (NTP) klient | Ja |
System logfil | Ja |
Varm reservedel | Ja |
Understøtter S.M.A.R.T. | Ja |
Filmappe | 1024 |
Gennemsnitstid mellem fejl (MTBF) | 159519 t |
Software | |
Understøttede Windows-operativsystemer | Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
Understøttede Linux-operativsystemer | Ja |
Understøttede Mac-operativsystemer | Ja |
Understøttede operativsystemer til servere | Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 |
Strømstyring | |
Placering af strømforsyning | Indbygget |
Strømforsyningens kapacitet (PCU) | 550 W |
Vekselstrømsindgangsspænding | 100-240 V |
Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
Vægt & størrelser | |
Bredde | 445 mm |
Dybde | 707 mm |
Højde | 88 mm |
Vægt | 12 kg |
Pakkebredde | 578 mm |
Pakkedybde | 880 mm |
Pakkehøjde | 248 mm |
Pakkevægt | 25,3 kg |
Emballage indhold | |
Pakketype | Kasse |
Processor særlige funktioner | |
Indlejret tilgængelige muligheder | Ingen |
Enhanced Intel SpeedStep Teknologi | Ja |
Udfør deaktivering af bit | Ja |
Grafisk og IMC litografi | 14 nm |
Idle status | Ja |
Intel® 64 | Ja |
Intel® klar video teknologi | Ja |
Intel® Enhanced Halt State | Ja |
Intel® Secure Key Technology version | 1,00 |
Intel® Trusted Execution Teknologi | Ja |
Intel® TSX-NI | Ja |
Intel® TSX-NI-version | 1,00 |
Intel® Virtualization Technology (VT-x) | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® AES Nye Instruktioner (Intel® AES-NI) | Ja |
Intel® Clear Video HD Teknologi (Intel® CVT HD) | Ja |
Intel® Clear Video Teknologi til MID (Intel® CVT for MID) | Ja |
Intel® Hyper Threading Teknologi (Intel® HT Technology) | Ja |
Intel® Insider™ | Ja |
Intel® InTru™ 3D Teknologi | Ja |
Intel® OS Guard | Ja |
Intel® Quick Sync Video Teknologi | Ja |
Intel® Sikker Nøgle | Ja |
Intel® Turbo Boost Teknologi | 2.0 |
Intel® Wireless Display (Intel® WiDi) | Ja |
Maksimalt antal PCI Express-kanaler | 16 |
Termiske overvågningsteknologier | Ja |
Hukommelseskanaler understøttet af processor | Dobbelt |
Hukommelsestyper understøttet af processor | DDR3L-SDRAM, DDR4-SDRAM |
Hukommelsesspænding understøttet af processor | 1,35 V |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Relativ luftfugtighed ved drift (H-H) | 20 - 80% |
Logistik data | |
Harmoniseret systemkode (HS) | 84714100 |
Andre funktioner | |
Compliance-certifikater | RoHS |
Certificering | FCC, CE, VCCI |
Processor ARK ID | 88173 |
