ATEN PSD PP v4.0 Secure KVM Switch CS1142DP4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1142DP4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).
ATEN PSD PP v4.0 Secure KVM Switch CS1142DP4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.
To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1142DP4C only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS) 1. With multi–layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1142DP4C ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.
Porte & Grænseflader | |
Antal kontrollerede computere | 2 |
Tastatur porttype | USB |
Mus porttype | USB |
Video porttype | DisplayPort |
Konsol porte | DisplayPort, USB A |
Antal DisplayPorts | 4 |
Antal USB 2.0 Type-B porte | 4 |
Antal konsol USB porte | 2 |
Antal konsol displayporte | 2 |
Antal USB 2.0 type-A hub porte | 1 |
Lydforbindelse | Ja |
Udgange til hovedtelefoner | 2 |
Antal RJ-11-porte | 1 |
Præstation | |
HD-type | 4K Ultra HD |
Maksimal opløsning | 3840 x 2160 pixel |
Design | |
Produktfarve | Sort |
Husmateriale | Metal |
Ledningsført fjernkontakt | Ja |
LED-indikatorer | Ja |
Trykknap | Ja |
Display | |
Indbygget skærm | Ingen |
Strømstyring | |
Strømkilde | Vekselstrøm |
Indgangsspænding | 100 - 240 V |
Vekselstrømsindgangsfrekvens | 50 - 60 Hz |
Indgangsstrøm | 1 A |
Strømforbrug (typisk) | 10,19 W |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 50 °C |
Opbevaringstemperatur (T-T) | -20 - 60 °C |
Relativ luftfugtighed ved drift (H-H) | 0 - 80% |
Vægt & størrelser | |
Bredde | 163,9 mm |
Dybde | 335 mm |
Højde | 65,5 mm |
Vægt | 2,33 kg |
Emballeringsdata | |
Pakkebredde | 131 mm |
Pakkedybde | 540 mm |
Pakkehøjde | 233 mm |
Pakkevolumen | 16480,4047212 cm³ |
Pakkevægt | 2,97 kg |
Emballage indhold | |
Kabler inkluderet | Vekselstrøm |
Brugervejledning | Ja |
Logistik data | |
Ydre emballage nettovægt | 6,99 kg |
Hovedkassens bredde (udvendigt) | 420 mm |
Hovedkassens længde (udvendigt) | 555 mm |
Hovedkassen højde (udvendigt) | 258 mm |
Hovedkassens bruttovægt (udvendigt) | 9,83 kg |
Ydre emballage volumen | 60144,9821784 cm³ |
Oprindelsesland | Taiwan |
