The Lindy 150m USB 2.0 Cat.6 Extender can be used to extend the distance between a USB peripheral device and host computer by up to 150m. It consists of a transmitter unit which connects to the computer and a receiver unit that connects to the device. Standard Cat.6 network cable (not included) is then used to bridge the connection between the two units. For best performance and compatibility, we recommend the use of solid core patched cables.
This USB 2.0 Extender is suitable for many long-distance applications like remote printing, camera surveillance or controlling machines. This USB 2.0 Extender is supplied with a power adapter for the receiver unit to ensure secure and uninterrupted power. The robust metal housing makes it ideal for rugged environments.
Tekniske detaljer | |
Type | Konsol sender & modtager |
Dataoverførselshastighed | 480 Mbit/s |
Maksimal overførselsafstand | 150 m |
Produktfarve | Sort |
Husmateriale | Metal |
LED-indikatorer | Aktivitet, Strøm |
Understøttede kabeltyper | Cat6 |
Compliance-certifikater | CE, Federal Communications Commission (FCC), REACH, RoHS |
Plug and play | Ja |
Overholdelse af bæredygtighed | Ja |
Porte & Grænseflader | |
Antal USB 2.0 type-A-porte | 1 |
Antal USB 2.0 Type-B porte | 1 |
Antal RJ-45-porte | 2 |
DC-in-stik | Ja |
Vægt & størrelser | |
Bredde | 67 mm |
Dybde | 32 mm |
Højde | 25 mm |
Transmitter vægt | 84 g |
Modtager vægt | 84 g |
Pakkebredde | 220 mm |
Pakkedybde | 194 mm |
Pakkehøjde | 60 mm |
Pakkevægt | 600 g |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 50 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Emballage indhold | |
Brugervejledning | Ja |
Strømstyring | |
Strømkilde type | DC |
Udgangsspænding | 5 V |
Udgangsstrøm | 3 A |
