Transform a Thunderbolt 4 laptop into a high-resolution multi-monitor workstation with 7x USB ports, 2.5 Gigabit Ethernet port, 3.5mm audio, plus USB Power Delivery and downstream device charging
This Thunderbolt 4 Certified docking station uses a single Thunderbolt 4/3 or USB4, port on a host computer to add high-performance connectivity while charging the laptop.
Flexible High-Performance Video Supporting up to Quad-Monitor 4K 60Hz
The dock is equipped with 2x HDMI and 2x DisplayPort video outputs for connecting multiple monitors to the host computer. The dock offers video flexibility, supporting single, dual, triple, or quad monitor configurations. With an Intel 12th Gen processor or higher that supports DP 1.4 with DSC, the docking station can support a quad-monitor configuration with resolutions up to 4K 60Hz. Quad displays are also available at lower resolutions or refresh rates on computers without DSC or with earlier Intel revisions. In addition, the dock supports a single 8K 60Hz display on either of the HDMI output ports.
Apple computers equipped with M1, M2, or M3 Max/Pro processors support dual displays. For Apple computers featuring the M1, M2, or M3 base processor a single display is supported.
Port Connectivity
The docking station utilizes the high 40Gbps throughput available from a Thunderbolt 4/3, or USB4 port to provide a wide range of port connectivity to suit a variety of applications.
The dock features:
• 2x HDMI ports to connect displays
• 2x DisplayPort ports to connect displays
• 6x USB 3.2 ports (3x 10Gbps Type-A, 1x 10Gbps Type-C, 2x 5Gbps Type-A) to connect USB peripheral devices
• 1x USB 2.0 (480Mbps) Type-A port that supports BC 1.2 with 7.5W (1.5A) for charging battery powered USB devices
• 1x 2.5 Gigabit Ethernet port with PXE boot and WoL to connect to a wired Local Area Network (LAN)
• 1x Secure Digital (SD) 4.0/UHS-II card reader to externally access SD, SDHC and SDXC memory cards
• 1x Micro Secure Digital (microSD) 4.0/UHS-II card reader to externally access mSD, mSDHC and mSDXC memory cards
• 1x 3.5mm 4-position TRRS Audio Jack to connect a 3.5mm headset
98W USB Power Delivery Certified
Includes a 180W power adapter and supports 98W USB power delivery. This enables the dock to charge the laptop, with enough additional power for the downstream USB 2.0 port to support BC 1.2 with 7W (1.5A) for charging tablets, smartphones or other battery-powered USB devices.
Enhance Productivity and Device Management with the StarTech.com Connectivity Tools App
Developed to improve performance and security, Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software includes:
•
Advanced Windows Layout Utility : To setup and save custom windows layouts.
•
Mac Address Pass-Through Utility : To improve network security.
•
USB Event Monitoring Utility : To track and log connected USB devices
•
Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.
For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-Tools
The StarTech.com Advantage
Porte & Grænseflader | |
Forbindelsesteknologi | Ledningsført |
Værtsgrænseflade | Thunderbolt 4 |
Antal USB 2.0-porte | 1 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 2 |
Antal HDMI-porte | 2 |
Udgange til hovedtelefoner | 1 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 3 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
USB strømforsyning | Ja |
USB strømforsyning revision | 3.0 |
USB strømforsyning op til | 98 W |
HDMI-version | 2.1 |
Antal DisplayPorts | 2 |
DisplayPort-version | 1.4 |
Kombineret hovedtelefon/mikrofon-port | Ja |
Tilslutning af hovedtelefoner | 3,5 mm |
DC-in-stik | Ja |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-porte (RJ-45) | 1 |
Ethernet LAN-datahastigheder | 10,100,1000,2500 Mbit/s |
Kobber ethernet kabelteknologi | 2.5GBASE-T, 10BASE-T, 100BASE-T, 1000BASE-T |
Fuld duplex | Ja |
Præstation | |
Produktfarve | Grå |
Indbygget kortlæser | Ja |
Kompatible hukommelseskort | MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
Dataoverførselshastighed | 40 Gbit/sek. |
HD-type | 8K Ultra HD |
Maksimal digital opløsning | 7680 x 4320 pixel |
Maksimal opdateringshastighed | 60 Hz |
Slot til kabellås | Ja |
Kabellåseslids type | Kensington, Nano |
Tænd-/slukkontakt | Ja |
LED-indikatorer | LAN, Strøm |
Understøtter UASP | Ja |
Husmateriale | Aluminium |
Strømstyring | |
Strømkilde type | DC |
Vekselstrømsindgangsspænding | 110 - 240 V |
Indgangsstrøm | 2.5 A |
Udgangsspænding | 20 V |
Udgangsstrøm | 9 A |
Strømforbrug (maks.) | 180 W |
Kompatible strømplug typer | EU, UK |
Software | |
Understøttede Windows-operativsystemer | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
Understøttede Mac-operativsystemer | Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 0 - 95% |
Vægt & størrelser | |
Bredde | 210 mm |
Dybde | 96 mm |
Højde | 34 mm |
Vægt | 200 g |
Emballeringsdata | |
Pakkebredde | 235 mm |
Pakkedybde | 145 mm |
Pakkehøjde | 90 mm |
Pakkevægt | 1,4 kg |
Emballage indhold | |
Kabler inkluderet | Thunderbolt |
AC-adapter inkluderet | Ja |
Hurtig start guide | Ja |
Tekniske detaljer | |
Compliance-certifikater | CE, RoHS |
Logistik data | |
Produkter pr. hovedkasse (udvendigt) | 4 stk |
Hovedkassens bredde (udvendigt) | 380 mm |
Hovedkassens længde (udvendigt) | 310 mm |
Hovedkassen højde (udvendigt) | 285 mm |
Andre funktioner | |
Chipsæt | Intel - JHL8440, Cypress - HX3PD, Parade - FL5801, Realtek - RTL8156BG, Genesys Logic - GL3231S, Realtek - ALC4030U, Realtek - RTD2188, Cypress - CCG5, TI - TPS2546 |
Bæredygtighed | |
Overholdelse af bæredygtighed | Ja |
