Turn a USB4 equipped laptop into a dual monitor workstation
This USB4 (USB-C 40Gbps) docking station uses a single USB4 or Thunderbolt port on a host computer to add high-performance connectivity while charging the laptop.
Flexible High-Performance Video
The dock is equipped with 2x HDMI 2.1 video outputs for connecting dual monitors to the host computer. The dock supports can support dual-monitors with support for resolutions up dual 4K 60Hz at 4:4:4 (RGB) or dual 4K 120Hz at 4:2:2. A single display workstation is also supported at resolutions up to 8K 30Hz 4:4:4 (RGB) or 8K 60Hz at 4:2:2.
Port Connectivity
The docking station utilizes the high 40Gbps throughput available from a Thunderbolt 4/3, or USB4 port to provide a wide range of port connectivity to suit a variety of applications.
The dock features:
• 2x HDMI ports to connect displays.
• 6x USB Hub (2x 10Gbps USB Type-A, 2x USB Type-A 5Gbps, 1x USB Type-C 10Gbps, 1x USB-C 5Gbps) to connect USB peripheral devices.
• 1x 2.5 Gigabit Ethernet port with PXE boot and WoL to connect to a wired Local Area Network (LAN)
100W USB Power Delivery
Includes a 180W power adapter and supports 100W USB power delivery. This enables the dock to charge the laptop, with enough additional power for all downstream ports. The 6-Port USB hub includes a 20W downstream USB-C Power Delivery port and a 7.5W BC 1.2 Downstream Charging Port (DCP) for charging tablets, smartphones or other battery-powered USB devices.
Enhance Productivity and Device Management with the StarTech.com Connectivity Tools App
Developed to improve performance and security, Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software includes:
•
Advanced Windows Layout Utility : To setup and save custom windows layouts.
•
Mac Address Pass-Through Utility : To improve network security.
•
USB Event Monitoring Utility : To track and log connected USB devices
•
Wi-Fi Auto Switch Utility : Enabling users to quickly access faster network speeds via wired LAN.
For more information and to download the StarTech.com Connectivity Tools application, please visit: www.StarTech.com/Connectivity-Tools
The StarTech.com Advantage
Porte & Grænseflader | |
Forbindelsesteknologi | Ledningsført |
Værtsgrænseflade | USB4 |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte | 1 |
Antal HDMI-porte | 2 |
Mikrofonindgang | Ingen |
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte | 1 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 2 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
USB strømforsyning | Ja |
USB strømforsyning op til | 100 W |
DC-in-stik | Ja |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-porte (RJ-45) | 1 |
Ethernet LAN-datahastigheder | 10,100,1000,2500 Mbit/s |
Wake-on-LAN klar | Ja |
Fuld duplex | Ja |
Præstation | |
Produktfarve | Sølv |
Indbygget kortlæser | Ingen |
Dataoverførselshastighed | 40 Gbit/sek. |
HD-type | 4K Ultra HD |
Maksimal digital opløsning | 3840 x 2160 pixel |
Antal understøttede skærme | 2 |
Maksimal opdateringshastighed | 120 Hz |
Slot til kabellås | Ja |
Kabellåseslids type | Kensington, Nano |
Tænd-/slukkontakt | Ja |
LED-indikatorer | Ja |
Understøtter UASP | Ja |
Husmateriale | Plast |
Strømstyring | |
Strømkilde type | DC |
Vekselstrømsindgangsspænding | 100 - 240 V |
Indgangsstrøm | 2.5 A |
Udgangsspænding | 20 V |
Udgangsstrøm | 9 A |
Strømforbrug (typisk) | 165 W |
Strømstiktype | Type M |
Kompatible strømplug typer | EU, UK |
Software | |
Understøttede Windows-operativsystemer | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64 |
Andre understøttede operativsystemer | ChromeOS |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -20 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 0 - 95% |
Vægt & størrelser | |
Bredde | 210 mm |
Dybde | 95 mm |
Højde | 34 mm |
Vægt | 138,6 g |
Emballeringsdata | |
Pakkebredde | 145 mm |
Pakkedybde | 230 mm |
Pakkehøjde | 89 mm |
Pakkevægt | 1,3 kg |
Emballage indhold | |
Kabler inkluderet | USB |
Hurtig start guide | Ja |
Logistik data | |
Produkter pr. hovedkasse (udvendigt) | 8 stk |
Hovedkassens bredde (udvendigt) | 305 mm |
Hovedkassens længde (udvendigt) | 375 mm |
Hovedkassen højde (udvendigt) | 265 mm |
Andre funktioner | |
Chipsæt | VIA - VL830, VIA - VL163, Realtek - RTD2188-VA-CG, Genesys Logic - GL9901NE |
