The DST-Pro USB4 of the latest USB4 generation is a high performance, multifunctional solution for connecting laptops, tablets or mobile phones to a range of interfaces including an 8K 30Hz DisplayPort or HDMI display or two displays simultaneously at 4K 60Hz*, using a single cable. It also supports video resolutions of 4K 120Hz, making it the ideal tool for high resolution video editing or game streaming.
This docking station delivers a whole host of capable ports to connect your devices into your workflow. With SuperSpeed USB and Ethernet, you can expect to have a blazing fast experience and improve your productivity whilst the Card Readers (SD and Micro-SD) allow you to expand your storage capacity beyond that of your device. Through a single USB-C cable, connect to multiple SuperSpeed 10Gbps USB Type A or Type C ports, a 3.5mm combined headphone jack, Gigabit Ethernet, (Micro-) SD card slots, DisplayPort and HDMI.
The USB4 Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop. A power supply is not included. The dock can be used with the power supply supplied with the laptop or a power supply can be purchased separately.
This USB4 Laptop Docking Station is compatible with computers featuring the USB Type C port with support for DisplayPort 1.4 Alternate Mode, i.e. USB4 or USB 3.2 as well as Thunderbolt 3 or TB4 host devices.
*Please note that macOS does not support MST.
Porte & Grænseflader | |
Forbindelsesteknologi | Docking |
Værtsgrænseflade | USB4 |
Antal USB 2.0-porte | 3 |
Antal HDMI-porte | 1 |
Mikrofonindgang | Ja |
Udgange til hovedtelefoner | 1 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte | 3 |
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte | 1 |
Antal USB4-porte | 1 |
PowerShare | Ja |
Antal USB-porte med understøttelse af PowerShare | 3 |
USB strømforsyning | Ja |
USB strømforsyning revision | 3.0 |
USB strømforsyning op til | 100 W |
HDMI-version | 2.1 |
Antal DisplayPorts | 1 |
DisplayPort-version | 1.4 |
Kombineret hovedtelefon/mikrofon-port | Ja |
Tilslutning af hovedtelefoner | 3,5 mm |
HDCP | Ja |
HDCP-version | 2.2 |
USB type-C DisplayPort alternativ tilstand | Ja |
Netværk | |
Ethernet LAN | Ja |
Ethernet LAN-porte (RJ-45) | 1 |
Ethernet LAN-datahastigheder | 1000 Mbit/s |
Præstation | |
Produktfarve | Anthracit |
Indbygget kortlæser | Ja |
Kompatible hukommelseskort | MicroSD (TransFlash), SD |
Dataoverførselshastighed | 1 Gbit/sek. |
Maksimal digital opløsning | 7680 x 4320 pixel |
Antal understøttede skærme | 2 |
Maksimal opdateringshastighed | 120 Hz |
Husmateriale | Aluminium |
Strømstyring | |
Strømkilde type | USB |
Strømforbrug (maks.) | 20 W |
Driftsbetingelser | |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -10 - 70 °C |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Vægt & størrelser | |
Bredde | 129 mm |
Dybde | 69,5 mm |
Højde | 48 mm |
Vægt | 300 g |
Emballeringsdata | |
Pakkebredde | 174 mm |
Pakkedybde | 151 mm |
Pakkehøjde | 56 mm |
Pakkevægt | 400 g |
Emballage indhold | |
Kabler inkluderet | USB Type-C til USB Type-C |
Brugervejledning | Ja |
Tekniske detaljer | |
Compliance-certifikater | CE, Federal Communications Commission (FCC), REACH, RoHS |
Bæredygtighed | |
Overholdelse af bæredygtighed | Ja |
