The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.
Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
Funktioner | |
5 GHz | Ja |
Maksimal dataoverførselshastighed | 1000 Mbit/s |
Ethernet LAN-datahastigheder | 10,100,1000 Mbit/s |
Gennemløbs datahastighed | 450 Mbit/s |
Frekvensbånd | 5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz |
Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
Maksimal udendørsinterval | 10000 m |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 1 |
Strømstyring | |
Strøm over Ethernet (PoE) | Ja |
Vekselstrømsindgangsspænding | 24 V |
Indgangsstrøm | 0.5 A |
Design | |
Placering | Loft |
Produktfarve | Hvid |
LED-indikatorer | Netværk, Strøm, Signalstyrke |
Certificering | CE, FCC, IC |
Antenne | |
Antenne type | Intern |
Præstation | |
Indbygget processer | Ja |
Intern hukommelse | 64 MB |
Operativsystem installeret | AirOS |
Vægt & størrelser | |
Bredde | 179 mm |
Dybde | 77,5 mm |
Højde | 59,1 mm |
Vægt | 180 g |
Driftsbetingelser | |
Relativ luftfugtighed ved drift (H-H) | 5 - 95% |
Driftstemperatur (T-T) | -40 - 70 °C |
Logistik data | |
Harmoniseret systemkode (HS) | 85176990 |
