Superior Wi-Fi Coverage for Outdoor Environments
Excellent Hardware Designs
With the special design of its antenna, appearance, power options and installation methods, EAP113-Outdoor can perfectly fit for different scenarios both indoors and outdoors.
Detachable Antennas
EAP113-Outdoor is designed with 2 Omni-directional detachable antennas, which means other antennas can also be attached for your specific demands.
Delicate Appearance Even Better for Indoor Applications
EAP113-Outdoor is just similar to a cellphone, with dimension: 8.5 × 1.8 × 1.5 in (214.9 × 46 × 37.7 mm)
Supports Passive PoE for Easy Outdoor Set up
EAP113-Outdoor supports both 802.3af PoE and 48V Passive PoE power supply, can be either powered by a PoE switch or a PoE adapter.
Flexible Deployment
EAP113-Outdoor can be easily installed to a pole or on a wall with the mounting kits provided.
Wi-Fi That Goes the Distance
With high transmission power and two high-gain omnidirectional antennas,
EAP113-Outdoor provides stable wireless coverage at a range of up to 200 meters* in outdoor settings.
Specially Designed Weatherproof Enclosure for Outdoor Environment
Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against the harsh outdoor condition.
Seamless Integrated into Omada SDN Platform
The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Funktioner | |
2.4 GHz | Ja |
5 GHz | Ingen |
6 GHz | Ingen |
Maksimal dataoverførselshastighed | 300 Mbit/s |
Netværksstandarder | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Wi-Fi-multimedie (WMM)/(WME) | Ja |
Vituelle LAN funktioner | VLAN-kortlægning |
Begrænsning af hastighed | Ja |
Trådløs isolation | Ja |
Servicekvalitet support (QoS) | Ja |
Sendeeffekt (CE) | 20 dBm |
Sendeeffekt (FCC) | 22 dBm |
Sikkerhed | |
Sikkerhedsalgoritmer | 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SNMPv2, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
Filtrering af MAC-adresser | Ja |
Service Set Identifier (SSID) funktioner | Multiple SSIDs |
Antal SSID understøttet | 8 |
Adgangskontrolliste (ACL) | Ja |
Administrationsfunktioner | |
Syslog | Ja |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 1 |
Strømstyring | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet (PoE) -type understøttet | Passive PoE |
DC spændingsområde | 48 V |
Strømforbrug (typisk) | 4,11 W |
Design | |
Placering | Pæl, Væg |
Produktfarve | Hvid |
Kode for international beskyttelse (IP) | IP65 |
Knap til nulstilling | Ja |
Certificering | CE, FCC, RoHS |
Antenne | |
Antenne type | Ekstern |
Antenneretningstype | Omniretningsbestemt |
Antennefunktioner | Aftagelig antenne |
Antenner, antal | 2 |
Niveau for antennestyrke (maks.) | 3 dBi |
Tekniske detaljer | |
Compliance-certifikater | CE, Federal Communications Commission (FCC), RoHS |
Vægt & størrelser | |
Bredde | 214,9 mm |
Dybde | 46 mm |
Højde | 37,7 mm |
Emballage indhold | |
Antal produkter inkluderet | 1 stk |
Monteringssæt | Ja |
Antenne inkluderet | Ja |
Driftsbetingelser | |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Driftstemperatur (T-T) | -30 - 65 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
Bæredygtighed | |
Overholdelse af bæredygtighed | Ja |
