An Affordable Business-Class
802.11ac MU-MIMO Wi-Fi Solution
Superior Wi-Fi Speeds with MU-MIMO Technology
Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP223 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.
Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Hassle-Free Centralized Cloud Management:
100% centralized cloud management of whole network from different sites—all controlled from a single interface anywhere, anytime.
Secure Guest Network with Facebook Wi-Fi and SMS Authentication
The captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP223 supports both 802.3af/at PoE and Passive PoE power supply, which can be either powered by a PoE switch or the PoE adapter, making deployment effortless and flexible.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
Funktioner | |
2.4 GHz | Ja |
5 GHz | Ja |
6 GHz | Ingen |
Maksimal dataoverførselshastighed | 867 Mbit/s |
Maksimal dataoverførselshastighed (2,4 GHz) | 450 Mbit/s |
Maksimal dataoverførselshastighed (5 GHz) | 867 Mbit/s |
Netværksstandarder | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Automatisk kanalvalg | Ja |
Automatisk kanalscanning | Ja |
MIMO | Ja |
MIMO type | Multi User MIMO |
Wi-Fi-multimedie (WMM)/(WME) | Ja |
VLAN understøttelse | Ja |
Begrænsning af hastighed | Ja |
Trådløs isolation | Ja |
Båndstyring | Ja |
Servicekvalitet support (QoS) | Ja |
Sendeeffekt (CE) | 20, 23 dBm |
Sendeeffekt (FCC) | 24, 22 dBm |
Sikkerhed | |
Sikkerhedsalgoritmer | SSID |
Filtrering af MAC-adresser | Ja |
Antal SSID understøttet | 15 |
Administrationsfunktioner | |
Webbaseret administration | Ja |
Syslog | Ja |
Administrationsplatform | Omada |
Porte & Grænseflader | |
Ethernet LAN-porte (RJ-45) | 1 |
Strømstyring | |
Strøm over Ethernet (PoE) | Ja |
Power over Ethernet (PoE) -type understøttet | Active PoE, Passive PoE |
Udgangsspænding | 48 V |
Strømforbrug (typisk) | 9,7 W |
Design | |
Placering | Loft, Væg |
Produktfarve | Hvid |
Knap til nulstilling | Ja |
LED-indikatorer | Strøm |
Certificering | CE, FCC, RoHS |
Antenne | |
Antenne type | Intern |
Antenneretningstype | Omniretningsbestemt |
Antenner, antal | 3 |
Præstation | |
Kompatible operativsystemer | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
Vægt & størrelser | |
Bredde | 205,5 mm |
Dybde | 181,5 mm |
Højde | 37,1 mm |
Emballage indhold | |
Antal produkter inkluderet | 1 stk |
Kabler inkluderet | Vekselstrøm |
Monteringssæt | Ja |
Hurtig start guide | Ja |
Driftsbetingelser | |
Relativ luftfugtighed ved drift (H-H) | 10 - 90% |
Driftstemperatur (T-T) | 0 - 40 °C |
Opbevaringstemperatur (T-T) | -40 - 70 °C |
Relativ luftfugtighed ved opbevaring (H-H) | 5 - 90% |
