Intel® Trusted Execution Technology
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Cache
CPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.
Instruction Set
An instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.
Intel® Quick Sync Video
Intel® Quick Sync Video delivers fast conversion of video for portable media players, online sharing, and video editing and authoring.
Intel® Wake on Voice
Intel® Wake on Voice allows your device to wait and listen for your command without consuming excessive power and battery life, as well as wake from modern standby.
Intel® Thunderbolt™ 4
Universal computer port that can dynamically adjust data and video bandwidth depending on the device and/or application.
Intel® VT-x with Extended Page Tables (EPT)
Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.
Intel® Flex Memory Access
Intel® Flex Memory Access facilitates easier upgrades by allowing different memory sizes to be populated and remain in dual-channel mode.
Secure Key
Intel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.
Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.
Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.
Instruction Set Extensions
Instruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).
Intel® High Definition Audio
Audio interface for codecs to communicate with Intel SoCs and chipsets.
Intel® Turbo Boost Max Technology 3.0 Frequency
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom. Intel® Turbo Boost Max Technology 3.0 frequency is the clock frequency of the CPU when running in this mode.
Intel® Turbo Boost Max Technology 3.0
Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.
Intel® Smart Sound Technology
Intel® Smart Sound Technology is an integrated audio DSP (Digital Signal Processor) built to handle audio, voice, and speech interaction. It allows the latest Intel® Core™ processor-based PCs to respond to your voice command quickly and offer high fidelity audio without impact system performance and battery life.
Intel® Image Processing Unit
Intel® Image Processing Unit is an integrated image signal processor with advanced hardware implementation that improves image and video quality of cameras.
Intel® Total Memory Encryption
TME – Total Memory Encryption (TME) helps protect data against exposure via physical attack on memory, such as cold-boot attacks.
Thermal Monitoring Technologies
Thermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.
Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.
Mode-based Execute Control (MBEC)
Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.
Intel® Boot Guard
Intel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.
Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
Processor | |
Processorserie | Intel® Core™ i3 |
Processorkerner | 8 |
Processor sokkel | LGA 1700 |
Kasse | Ingen |
Processorproducent | Intel |
Processormodel | i3-12300HL |
Processorens basisfrekvens | 2 GHz |
Processor driftstilstande | 64-bit |
Processorgeneration | 12th gen Intel® Core™ i3 |
Processortråde | 12 |
Performance-kerner | 4 |
Effektive kerner | 4 |
Processor boost frekvens | 4,4 GHz |
Boostfrekvens af performancekerne | 4,4 GHz |
Boostfrekvens af effektiv kerne | 3,3 GHz |
Processor-cache | 12 MB |
Processor cache type | Smart cache |
Processor base power | 45 W |
Maksimal sikret effekt | 65 W |
Minimum garanteret effekt | 35 W |
Stepping | L0 |
Processor kodenavn | Alder Lake |
Processor ARK ID | 219491 |
Hukommelse | |
Hukommelseskanaler | To-kanals |
Maksimal intern hukommelse understøttet af processor | 64 GB |
Hukommelsestyper understøttet af processor | DDR4-SDRAM, DDR5-SDRAM |
Fejlkorrigerende kode | Ingen |
Grafik | |
On-board grafikkort | Ja |
Diskret grafikadapter | Ingen |
On-board grafikkort, model | Intel Iris Xe Graphics |
Diskret grafikadaptermodel | Ikke tilgængelig |
Understøttelse af indbyggede grafikadapterudgange | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
Indbygget grafikadapter dynamisk frekvens (maks.) | 1400 MHz |
Antal understøttede skærme (indbygget grafik) | 4 |
Indbygget grafikadapter DirectX-version | 12.1 |
Indbygget grafikadapter OpenGL-version | 4.6 |
Indbygget grafikadapter maksimal opløsning (DisplayPort) | 7680 x 4320 pixel |
Indbygget grafikadapter maksimal opløsning (eDP- integreret fladskærm) | 4096 x 2304 pixel |
Indbygget grafikadapter maksimal opløsning (HDMI) | 4096 x 2304 pixel |
Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (DisplayPort) | 60 Hz |
Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (eDP-integreret fladskærm) | 120 Hz |
Opdateringshastighed for indbygget grafikadapter ved maksimal opløsning (HDMI) | 60 Hz |
Indbygget grafikadapter-ID | 0x46A3 |
Antal udførelsesenheder | 48 |
Multi-format codec-motorer | 2 |
Funktioner | |
Udfør deaktivering af bit | Ja |
Termiske overvågningsteknologier | Ja |
Markedssegment | Embedded |
Brugsbetingelser | PC/Client/Tablet |
Maksimalt antal PCI Express-kanaler | 20 |
PCI Express slots version | 4.0 |
Understøttede instruktionssæt | AVX 2.0, SSE4.1, SSE4.2 |
CPU-konfiguration (maks.) | 1 |
Indlejret tilgængelige muligheder | Ja |
Eksportkontrolklassisfikationsnummer (ECCN) | 5A992C |
Automatiseret sporingssystem til vareklassificering (CCATS) | G167599 |
Processor særlige funktioner | |
Intel® Hyper Threading Teknologi (Intel® HT Technology) | Ja |
Intel® Quick Sync Video Teknologi | Ja |
Intel® Flex Memory Access | Ja |
Intel® AES Nye Instruktioner (Intel® AES-NI) | Ja |
Intel® Trusted Execution Teknologi | Ja |
Intel® Speed Shift Technology | Ja |
Intel® Turbo Boost Max Technology 3.0-frekvens | 4,4 GHz |
Intel® fuld hukommelseskryptering | Ja |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Ja |
Intel® Thunderbolt 4 | Ja |
Intel® billedbehandlingsenhed | 6.0 |
Intel® Wake on Voice | Ja |
Intel® CET (Control-flow Enforcement Technology) | Ja |
Intel® Thread Director | Ja |
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® Sikker Nøgle | Ja |
Intel HD Audio Teknologi | Ja |
Intel® Active Management Teknologi (Intel® AMT) | Ja |
Intel® OS Guard | Ja |
Intel® Smart lyd teknologi | Ja |
Intel® Virtualization Technology (VT-x) | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Turbo Boost Max Teknologi 3.0 | Ja |
Intel® Boot Guard | Ja |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Ja |
Mønsterbaseret eksekveringskontrol (MBE) | Ja |
Intel® Standard Manageability (ISM) | Ja |
Chipset / PCH PCIe Revision | Gen 3 |
MIPI SoundWire | 1.2 |
Intel® Total Memory Encryption - Multi Key | Ja |
Driftsbetingelser | |
Tjunction | 100 °C |
Tekniske detaljer | |
OpenCL version | 3.0 |
Understøttede hukommelsestyper | DDR4-SDRAM, DDR5-SDRAM |
Lanceringsdato | Q3'22 |
Status | Launched |
Logistik data | |
Harmoniseret systemkode (HS) | 8542310001 |
Vægt & størrelser | |
Processor-pakke størrelse | 45 x 37.5 mm |
Andre funktioner | |
Grafikudgang | eDP 1.4b, DP 1.4a, HDMI 2.1 |
